Models

Description
Drive Train
Production

Willys-Overland MB front view

Description

The MA was the prototype that won Willys the contract with the U.S. Government. Willys built approximately 1550 of them in 1941. From late 1941 until mid 1945, Willys built MBs and Ford built GPWs based on the Willys design.

The first 25,808 MBs produced by Willys used a "slat grill". This grill was welded together rather than the stamped grill most people are familiar with. Very few "slat grill" MBs remain in existence.

Willys-Overland MB back view

Drive Train

The MA, MB, and GPW used the "Go Devil" L-head 134 I4 engine, T-84 3 Speed manual transmission, Dana 18 two speed transfer case, Dana 25 front axle, and Dana 23-2 rear axle.

Production Information

MA

Year Serial Number Range Production
1941 78401 - 79900 1500
1941 85501 - 85550 50

MB

Year Serial Number Range Production
1941 100001 - 108598 8598
1942 108599 - 200022 91424
1943 200023 - 293232 93210
1944 293233 - 402334 109102
1945 402335 - 459851 57517

GPW

Year Serial Number Range Production
1942 - ?
1943 - ?
1944 - ?
1945 - ?

Serial numbers are located on the left front of the frame and on the back of the bumper. The engine number was located at the front of the engine block on the water pump boss.

Contributor

Thanks to Charlie Weaver for sending me the MA and MB serial numbers.
